The Automatic Telescoping Passageway Conveyor is completely automated. When its sensors detect the presence of someone wishing to cross the production line, the conveyor is halted momentarily, and the machine automatically telescopes into the housing to create a passageway. Immediately after the line is crossed, the conveyor returns to its normal position, saving time and increasing efficiency.

Kategori: ,

Keterangan

Fitur

  • LED touch screen control
  • Retractable mechanism area fully enclosed design, ensures operational security
  • Top cover can be opened for easy access to maintenance
  • Penyesuaian lebar paralel dan halus ( by lead screw)
  • Expansion and contraction Fast,Smooth (Stepper motor)
  • Minimize clearance between conveyor
  • Safety sensor installed to enhance safety
  • 700mm passage way or specify
  • Antarmuka SMEMA yang kompatibel



Model Dimensi (MM) Ukuran PCB (MM) Berat (kg)
TSC-350 1500*650*1050 50*50-445*350 200
TSC-460 1500*760*1050 50*50-530*460 230



Barang Parameter Teknis
Convey speed 0.5-20M per minute (Atau disesuaikan)
Belt type Oblate belt
Ketinggian Transportasi 90020mm (Atau disesuaikan)
Arah Transportasi Dari kiri ke kanan atau kanan ke kiri
Catu daya utama AC:110 atau 220 V , 200W
Sumber Udara 4~6Kgf/cm2
